Application: Fire Resistant – Mains and Sub-Mains, Fire Alarm Systems, Essential Services
Construction:
1. Conductor – Plain annealed class 5 flexible copper
2. Fire Resistant layer – Mica Tape
3. Insulation – Cross-linked low-smoke halogen-free polyolefin compound (X-HF-110)
4. Filler – Flame retardant material
5. Binder Tape – Low smoke halogen-free flame retardant tape
6. Outer sheath – Cross-linked low-smoke halogen-free polyolefin compound (HFS-110-TP)
Cross Section:
2 core: 1.5~400mm2
3 core: 1.5~400mm2
4 core: 1.5~400mm2
5 core: 1.5~400mm2
2 core + earth: 1.5~400mm2
3 core + earth: 1.5~400mm2
4 core + earth: 1.5~400mm2
Temperature characteristics:
Conductor operating temperature: -40ºC~110ºC
Min. temperatrue laying condition: 0ºC
Electrical Characteristics:
Rated voltage: 0.6/1 (1.2) kV
High voltage test: 3.5kV / 5min
Color:
Insulation:
2 core: Red, Black
3 core: Red, White, Blue
4 core: Red, White, Blue, Black
5 core: Red, White, Blue, Black, Y/G
2 core + earth: Red, Black, Y/G
3 core + earth: Red, White, Blue, Y/G
4 core + earth: Red, White, Blue, Black, Y/G
Sheath: Red or according to customer requirements
Standard:
Cable design: AS/NZS5000.1
Conductor: AS/NZS 1125
Fire resistant : AS/NZS3013 (WS52W)
| Size | Conductor Strands | Insulation Thickness |
| 2×1.5mm2 | 7/0.52mm | 0.6mm |
| 2×2.5mm2 | 7/0.68mm | 0.7mm |
| 2×1.5mm2+1.5mm2 | 7/0.52mm | 0.6mm |
| 2×2.5mm2+2.5mm2 | 7/0.68mm | 0.7mm |
| 2x4mm2+2.5mm2 | 7/0.85mm+7/0.68mm | 0.8mm |
| 2x6mm2+2.5mm2 | 7/1.04mm+7/0.68mm | 0.8m |
