| Item | Unit | Spec. Value | |
| Conductor
|
Wire No. | — | 4P |
| Material | — | Solid Bare Copper | |
| Construction | No./mm | 0.57±0.02 | |
| Insulation
|
Material | — | PE |
| Diameter | mm | 1.16±0.05 | |
| Color | — | 1.Blue&White Blue 2.Orange&White Orange
3.Green&White Green 4.Brown&White Brown |
|
| Seperator | — | / | Yes |
| Tape Wrap | Spec | mm | PET 100％Coverage |
| Foil Shield | Spec | mm | AL-Mylar 100％Coverage |
| Drain Wire | Material | — | Tinned copper |
| Spec | mm | 0.4±0.05 | |
| Rip cord | — | / | Yes |
| Jacket | Material | — | PVC |
| Color | — | Assorted upon request | |
| Thickness | mm | 0.55±0.1 | |
| Diameter | mm | 7.8±0.5 | |
|
Frequency（MHz）
|
ATT (≤dB)
|
NEXT (≥dB)
|
PSNEXT (≥dB)
|
ELFEXT (≥dB)
|
PS ELFEXT (≥dB)
|
RL (≥dB)
|
|
1.00
|
2.0
|
74.3
|
72.3
|
67.8
|
64.8
|
20.0
|
|
4.00
|
3.8
|
65.3
|
63.3
|
55.8
|
52.8
|
23.0
|
|
8.00
|
5.3
|
60.8
|
58.8
|
49.7
|
46.7
|
24.5
|
|
10.00
|
6.0
|
59.3
|
57.3
|
47.8
|
44.8
|
25.0
|
|
16.00
|
7.6
|
56.2
|
54.2
|
43.7
|
40.7
|
25.0
|
|
20.00
|
8.5
|
54.8
|
52.8
|
41.8
|
38.8
|
25.0
|
|
25.00
|
9.5
|
53.3
|
51.3
|
39.8
|
36.8
|
24.3
|
|
31.25
|
10.7
|
51.9
|
49.9
|
37.9
|
34.9
|
23.6
|
|
62.50
|
15.4
|
47.4
|
45.4
|
31.9
|
28.9
|
21.5
|
|
100.00
|
19.8
|
44.3
|
42.3
|
27.8
|
24.8
|
20.1
|
|
200.00
|
29.0
|
39.8
|
37.8
|
21.8
|
18.8
|
18.0
|
|
250.00
|
32.8
|
38.3
|
36.3
|
19.8
|
16.8
|
17.3
|
