XLPE Insulated Power Cable
Power cables are cables used to transmit and distribute electrical energy. Power cables are often used in urban underground power grids, power station outgoing lines, internal power supply in industrial and mining enterprises, and underwater transmission lines across the river.
YUNI cables are the backbone cables in power transmission. They are usually found in urban underground passages (underground manhole covers) or buried underground. Construction teams often cut off the power cables during construction and cause large-scale power outages.
| Product Name | Copper core or aluminum core XLPE insulated PVC sheathed power cable Copper core or aluminum core XLPE insulated steel tape armoured PVC sheathed power cable Copper core or aluminum core XLPE insulated steel wire armoured PVC sheathed power cable |
| Rated Voltage | 0.6/1kv 1.8/3kv 3.6/6kv 6/10kv 8.7/15kv 12/20kv 21/35kv 26/35kv |
| Standard | B/T12706-2008,GB/T12703-200,IEC60502-1-1997 |
| Model | YUNI22 YUNIV22 YUNIV32 YUNIV32 YUNIV42 YUNIV42 |
| Armoured | Steel tape armored, steel wire armored, Double of galvanized steel tape or galvanized steel wire for three core power cable ,Double of aluminium tape or aluminium wire for single power cable |
| Number of cores | Single core, 2 cores, 3 cores, 4 cores, 5 cores, 3+1 cores, 3+2 cores, 4+1 cores, etc. |
| Common size | 1mm², 1.5mm², 2.5mm², 4mm², 6mm², 10mm², 16mm², 25mm², 35mm², 50mm², 70mm², 95mm², 120mm², 150mm², 185mm², 240mm², 300mm², 400mm², 500mm², 630mm², 800mm², 1000mm², etc. |
| Types | Ordinary type, flame-retardant type, fire-resistant type, low-smoke halogen-free type |
| Application | power distribution engineering, power transmission engineering, electromechanical and hydropower installation engineering, power transmission, power supply installation system, control system, etc. |
